SMD2835 - 140leds/m-6mm
Feature / Warranty:
◆ Super bright leds, stable and reliable.
◆ High lumen output, can be 150lm/W, Ra80/Ra90/Ra95 available.
◆ High cost-effective compare with SMD3528/5050 strip.
◆ One BIN LED selection to ensure color consistency.
◆ CE/ROHS certification.
◆ Warranty: 3 years.
IP rate:
Specification:
| Model No. | CH-2835W140-5M-24V-K6 | ||
|---|---|---|---|
| Step length (mm/x LED) | 50mm/7LEDs | ||
| Number LED/m | 140leds/m | ||
| Voltage (v) | 24V | ||
| Ra | 80 / 90 / 95 | ||
| Beam Angle(º) | 120º | ||
| Power (w/m) | 10.5W/m | ||
| Light output (lm/m) | 1210lm/m | ||
| FPC width (mm) | 6mm | ||
| Color Temperature(CCT) | 2200-7000K | ||
| Max. length per circuit (m) | 5m | ||
| IP rate | 20/65/66/67/68 | ||
| Package | 2.5Mts/Reel, Anti-Static Bag + Carton | ||
| Installation | 3M Tape / Mounting Clips / Aluminum Profiles | ||
Dimensions & available lengths
